Self Checkout Kiosk Mini

In stock

Our wall-mounted, interactive Self Checkout Kiosks help you drive sales, reduce operational costs, and improve speed of service at your hospitality venue.

Self service kiosks allow your customers to order and pay themselves, while the full integration with Grafterr Hospitality software suite puts you in full control of the experience they see - included customisation options allow you to easily adjust the images, designs and even button colours to match your existing branding.

Powerful reporting and payment solutions built-in

With the power of the included ePOS software suite at its core, your kiosk can seamlessly synchronise your existing POS food menus, send orders directly to the kitchen for preparation, instantly process card payments, scan gift vouchers, and even promote and up-sell additional items for an average increase in order size of up to 20%.

The included reporting suite provides an in-depth insight into your best selling items and customer orders, while all other business-crucial data is only a few clicks away inside the cloud back-office.


Checkout Kiosk Mini package features:

  • Self-service kiosk with a 24 inch HD touchscreen and Wi-Fi/LAN connectivity
  • Full integration with our ePOS software that lets you gain powerful insights into your customers and sales
  • A sleek, space-saving design perfect for smaller hospitality venues
  • Fully customisable checkout experience allows customers to choose between eat-in or take away orders, cash or card payments, apply gift vouchers and more
  • Simple ordering and payment interface that lets customers order & pay on their own
  • Built-in automatic upselling of additional items, increasing average order size by up to 20%
  • An integrated customer receipt printer and voucher/QR code scanner


Included in the box:

  • 24" touch screen self checkout kiosk
  • Metal bracket for wall mounting
  • All cables required for installation

RTC real - time clock : Support
2-D: : PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc.
1-D: : UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
Print Contrast : 25% minimum reflective difference
Interfaces Supported : USB, RS232
Motion Tolerances : up to 600cm per second
Roll/Pitch/Yaw : 360°, ±65°, ±60°
Field of View : 50° (H) x 35° (V)
Driver : Windows98/2000/NT/XP/VISTA/WIN7/WIN8/LINUX
Scanner Light Source : Illumination: 617nm RED LED
Auto cutter method : Automatic paper cutting function
Power Supply : DC24V, 2A
Emulation : ESC/POS
Printing Resolution : 8 dots/mm,576 dots/line
Paper Width : 80mm
Printing Speed : 170 mm/s
Printing Method : Thermal Line printing
Image Format Support : Supports: BMP, JPEG, PNG, GIF
Video Format Support : Supports: wmv, avi, rm, rmvb, mpeg, ts, mp4
Time - power - off : Support
Ethernet : 1@, 100M/1000M Ethernet
WIFI, BT : Built in WIFI, BT4.0(optional) support dual frequency WIFI, dual antenna
3G/4G (optional) : Built in WCDMA, EVDO, 4G Full Netcom, Supports voice calls
HDMI Output : 1@support 1080P@60Hz,4kx2k@60Hz output
USB Interface : 6 insert pin, 2 standard USB interface
Serial Port : 5 channels serial port (3*232;1*TTL;1*485)
ROM : 16GB
CPU : Rockchip RK3399 higest64 bits CPU,Main Frequency 2.0GHz;1.Big,Little architecture;Dual-core Cortex-A72 + Quad Cortex- A53;2.Built-in low power consumption Mcu Cortex-Mo GPU:Quad Cortex-Mali-T860MP4;Android 7.1
Touch Screen Transparency : 87±2%
Touch Screen Type : 10 - point capacitive touch screen
Screen Resolution : 1920*1080
ResponseTime : 8ms
Viewing Angle : 178/178
Screen Contrast Ratio : 1000:1
Screen Brightness : 250cd/㎡
Screen Size : 24"
Screen Brand : BOE
Minimum Resolution : 4 mil code 39
Speakers : 8Ω 5W Active loud speaker
Operating Temperature : 0 ~ 40℃ (32 ~ 104F)
Storage Temperature : 10 ~ 95% @ 40℃
Power Input : AC 100-240V
Dimensions (W x H x D) : 37 x 85 x 9.5cm
Weight : 19kg
Installation : Wall mounted/fix on stand

Self Checkout Kiosk Mini + Payments

Self-Service Kiosks £799.00 + VAT

WisePad 3 Wireless Card Reader

Payment Devices £44.00 + VAT

WisePOS-E Touchscreen Payment Terminal

Payment Devices £165.00 + VAT

Tab 2

Yay! we successfully came to tab 2 ??

Tab 3

Yay! we successfully came to tab 3 ?

Was £2598.00 70% off
Now £769.00 EX VAT

Choose your colour:

UK Mainland Shipping (2-4 Working Days): £39.99


Frequently asked questions

While the checkout comes with our software preinstalled, you’ll need to subscribe to a monthly software subscription to activate it. Our packages start at just £49 p/m for a single kiosk.

You’ll get a 1 year warranty with all your hardware. If your kiosk breaks, we’ll send you a brand new replacement within 24 hours!

All of our self checkouts are plug & play and come with a handy installation guide. To install your self checkout, you’ll need two mains sockets for power nearby, and we always recommend using a LAN connection, but you can use WiFi if you prefer.
